Computed Tomography (CT)

Computed Tomography (CT)

Description of device:3D high resolution images could be acquired through a v/tome/x s micro-CT scanner from GE phoenix using a high-power nanofocus X-ray tube.  Pixel/voxel resolution are possible down to  2 μm depending on sample size.

ct-1
GE phoenix® v/tome/x s micro-CT scanner

ct-2
Tonalite sample in front of scintillator screen at ANTARES beam line at FRM II

ct-3
3D reconstruction of mafic phases of the tonalite sample

In addition we have a cooperation with Dr. Burkhard Schillinger from the ANTARES beamline at FRMII / Garching to perform neutron computed tomography. Pixel/voxel resolution are possible down to  20 μm depending on sample size.
More information is available at:
http://www.frm2.tum.de/en/science/radiography/antares/description/index.html
